Had cpu 01 missing component - name and orientantion please

hey guys,

whats the name and orientation of the missing component next to max? can i harvest the component from a previous mainboard revision?

best regards

0.22uH inductor. Non-directional

1 Like

thx do you know which ones exactly looks like there are a few with different specs. or doesnt it matter? if not which size?

can i buy the following:

also is the missing inductor an indication that the max ic maybe faulty? black screen charging with .44a. had some corrosion in the usb port and pi3 was shorted.

In the datasheet of the max77812 is a note:

The replacement shouldn’t be too far off the listed values.
