Question regarding caps around ALC5639

Nintendo Questions Nintendo Switch Lite
1

Hey all,

I managed to send 3 caps between the ALC5639 chip and the FPC connector flying off into the ether and am struggling to determine with confidence exactly what size/rating I need to look out for as replacements. I can’t post pics or links, so I’m hoping someone might be able to shed some light on the general cap situation around ALC5639. Any help would be very much appreciated.

2

PUT LINKwith (…) like i,e.
(…)imgur.com(…)/xxxxxx

3

Everything I try to link the pic is not letting me do it… here it is separated out:

imgur . com /RSlGLS8

4

check from Pg7

1 Like
5

Thanks, that was helpful. Based on the Datasheet, it appears I’m looking at

  1. 2.2uF/6.3v
  2. 0.1uF/6.3v
  3. 10uF/6.3v

The problem I’m facing now is determining what size they are (0402, 0603, etc.). Is anyone able to confirm?

6

smallest is 0201
So I guess #1 0402 #2 0201 #3 0603. Don’t have lite board by hand, Sorry

1 Like
7

Thanks again, those sizes seem highly likely to me. I’m ordering the caps and will add the final solution to this post for posterity.

8

Anybody know if these capacitor values ended up being correct? I’m trying to fix a switch lite with error 2153-0321 so I was changing out the ALC5639 and disturbed those same 3 caps as OP. I measured them while off the board and got 3.9uf for cap #3. Wondering if I maybe stumbled on my problem or OP had the wrong value for #3. Looking at the datasheet as a layperson I don’t see where they got 10uf for cap #3. Any guidance would would be greatly appreciated!

9

Now I see where they got 10uf so apparently my cap faulty. Lucky duck.

10

Good luck getting that 0201 back in position. Was a huge pain without a micropencil. Try not find to turn that FPC connector into a goopy mess too…

11

Man I gotta say your post absolutely made the difference in my repair. Thanks! I got the caps back on with hot air and used some aluminum tape to protect the FPC connectors. I ended up actually replacing 3 other caps around the ALC5639 before sound started working again. The chip wasn’t the problem it was the faulty caps.

1 Like
12

To avoid melting the fan connector on a switch lite, you can actually bottom hot air removing connector first, then work on the ALC audio chip or the close by area :joy:
FYI, white FPC connector tends to be more easier got melt than black ones :sweat_smile:(LCD or game cartridge one)
